XPE FOAM MSX05

XPE FOAM MSX05

XPE foam (chemically cross-linked polyethylene foam material) is made of polyethylene resin, foaming agent and other filling materials after being uniformly extruded and then foamed by high temperature. XPE foam has excellent characteristics such as waterproof, moisture-proof, cushioning, rebound, heat preservation, heat insulation, weather resistance, aging resistance, corrosion resistance, light weight, easy processing and forming.

Physical Property Table (TDS):

Product Crosslinked polyethylene foam
Times 5B
PHYSICAL PROPERTIES TEST METHOD METRIC UNITS
Density - Nominal ISO 845:2006 GB/T 6343-2009 kg/m³ 200±30
Shore Hardness Shore C LX-C ° ≥65
Size limit Thickness Internal mm 3~6
Width ≤1200
Tensile Strength TD ISO 1798:2008 GB/T 6344-2008 MPa ≥1300
MD ≥1500
Elongation at Break TD ISO 1798:2008 GB/T 6344-2008 % ≥140
MD ≥140
Tear strength TD QB/T 1130-91 KN/m ≥8
MD ≥8
Dimension Stability (80℃,24h) TD ISO 2796:1986 GB/T 8811-2008 % ≤±1.0
MD ≤±1.5
Water Absorption under 50% RH condition ISO 62:2008 GB/T 1034-2008 % ≤0.2
Thermal Conductivity ISO 8302:1991 GB/T 10294-2008 W/(m.k) ≤0.045

Application Scenarios and Performance Requirements:

Performance Indicators: Thermal conductivity, flame retardancy, resistance to electrolyte corrosion

Performance Indicators: Compression resistance, antistatic property, temperature resistance

Performance Indicators: Sound insulation, compression resistance, temperature resistance

Performance Indicators: Antimicrobial property, degradability
