Processed FOAM Slitting Foam

Processed FOAM Slitting Foam
We can help you to solve slitting offerings with the help of our sophisticated equipment and experienced specialists. In any case, we specialize in shut tolerance slitting and will meet your requirements at each program. Don’t hesitate to contact with MEISHUO for your customized products and slitting needs.
Physical Property Table (TDS):
Product | Crosslinked polyethylene foam | ||||||||
Times | 5B | 10B | 15B | 20B | 25B | 30B | |||
PHYSICAL PROPERTIES | TEST METHOD | METRIC UNITS | / | ||||||
Density - Nominal | ISO 845:2006 GB/T 6343-2009 | kg/m³ | 200±30 | 100±10 | 66±8 | 50±6 | 40±5 | 33±5 | |
Shore Hardness | Shore C | LX-C | ° | ≥65 | 55±5 | 45±5 | 35±5 | 30±5 | 25±5 |
Size limit | Thickness | Internal | mm | 3~6 | 3~8 | 3~8 | 3~10 | 3~12 | 3~15 |
Width | ≤1200 | ≤1600 | ≤1800 | ≤1800 | ≤1800 | ≤1800 | |||
Tensile Strength | TD | ISO 1798:2008 GB/T 6344-2008 | MPa | ≥1300 | ≥700 | ≥400 | ≥300 | ≥250 | ≥200 |
MD | ≥1500 | ≥800 | ≥500 | ≥400 | ≥300 | ≥200 | |||
Elongation at Break | TD | ISO 1798:2008 GB/T 6344-2008 | % | ≥140 | ≥130 | ≥120 | ≥110 | ≥100 | ≥90 |
MD | ≥140 | ≥130 | ≥120 | ≥110 | ≥100 | ≥90 | |||
Tear strength | TD | QB/T 1130-91 | KN/m | ≥8 | ≥5 | ≥3 | ≥2 | ≥1.5 | ≥1.2 |
MD | ≥8 | ≥5 | ≥3 | ≥2 | ≥1.5 | ≥1.2 | |||
Dimension Stability (80℃,24h) | TD | ISO 2796:1986 GB/T 8811-2008 | % | ≤±1.0 | ≤±1.0 | ≤±1.5 | ≤±2.0 | ≤±3.0 | ≤±3.0 |
MD | ≤±1.5 | ≤±2.0 | ≤±3.0 | ≤±3.5 | ≤±4.0 | ≤±5.0 | |||
Water Absorption | under 50% RH condition | ISO 62:2008 GB/T 1034-2008 | % | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 | ≤0.3 |
Thermal Conductivity | ISO 8302:1991 GB/T 10294-2008 | W/(m.k) | ≤0.045 | ≤0.045 | ≤0.045 | ≤0.04 | ≤0.04 | ≤0.04 |
Application Scenarios and Performance Requirements:
Performance Indicators: High-temperature resistance, flame retardancy, rebound resilience
Performance Indicators: Thermal insulation, water resistance, aging resistance
Performance Indicators: Environmental non-toxicity, tear resistance, rebound resilience
